AccuLine TNplus 6-10 kVA

Category: Uninterruptible Power Supplies (UPS)

[:en]

AccuLine TNplus double conversion are high-performance On line UPS with great reliability, suitable to support sensitive professional equipment and generally equipment that requires a continuous and quality supply of electricity. With an input power factor exceeding 99% and an output power factor (cosφ) of up to 0.9, they provide stable voltage and frequency without fluctuations or distortions of their operating characteristics. In addition, the models with the “S” designation provide the possibility of long autonomy by connecting an external battery cabinet.

[:en]

AccuLine TNplus UPS systems, with double conversion online topology, are top-performance UPS systems of significant reliability, suitable for supporting sensitive equipment that requires continuous, high-quality power supply. With an input power factor that exceeds 99% and an output power factor (cosφ) up to 0.9, provide stable voltage and frequency at their outputs, without fluctuations or distortions of operational characteristics. Furthermore, models with an “S” following their model number, provide the option of additional back-up time by connecting an external battery cabinet to them.

[:]

Share it:

[:en]• Tolerances over a wide range of input voltage fluctuations.
• DSP (Digital Signal Processing) technology to ensure ideal operating conditions for supported equipment.
• ECO mode.
• Adjustable output voltage and frequency.
• Protection against dips, surges, overloads, short circuits and power outages.
• Self-check function.
• USB port for connection to a PC.
• DB9 dry contact connector.
• Management program for checking the battery and UPS status, auto shutdown, etc. (available as a free download from the internet).
• “Smart charger” that adjusts the charging intensity depending on the ambient temperature.
• SNMP / AS400 (Relay card) / Modbus-Jbus card slot.
• Emergency Power Outage (EPO).
• LCD screen on the front for monitoring its operation.
• Output terminal block.
• Possibility of paralleling up to 4 units.
• Low noise level.
• Fan speed control to minimize noise.
• Guarantee of proper operation of the UPS and its batteries for 24 months.

UPS model	Dimensions (WxHxD)	Weight	Back-up time
TNplus 6000	260 x 708 x 550 mm	80 kg	5 minutes
TNplus 6000S	260 x 708 x 550 mm	25.5 kg	5 minutes
TNplus 10000	260 x 708 x 550 mm	84 kg	4 minutes
TNplus 10000S	260 x 708 x 550 mm	29.5 kg	4 minutes

(The letter “S” in the model name indicates a UPS without internal batteries and a built-in charger capable of supporting the connection of multiple external batteries for truly long autonomy).

AccuLine-Tnplus-6-10kva-series-brochure

USER-MANUAL-ACCULINE-TNplus-6000-10000VA

[:en]• Wide range input voltage fluctuation tolerance.
• DSP technology (Digital Signal Processing) that ensures ideal operating conditions for the supported equipment.
• ECO Mode (High Efficiency mode).
• Output voltage and frequency regulation.
• Protection from dips, over-voltages, overcharge, short-circuits and power cuts.
• Auto self-testing system.
• USB port for computer connection.
• DB9 dry contact terminal.
• Management Software for UPS / Battery monitoring & auto-shutdown.
• Temperature compensation charger
• SNMP card / AS400 (Relay card) / Modbus-Jbus slot.
• Emergency Power Off (EPO).
• LCD screen display.
• Output terminal block.
• Parallel connection capability up to 4 units.
• Low noise level.
• Fan speed control to minimize operation noise.
• 24-month warranty period covering UPS unit and internal batteries.

UPS Model	Dimensions (WxHxD)	Weight	Back-up time
TNplus 6000	260 x 708 x 550 mm	80 kg	5 minutes
TNplus 6000S	260 x 708 x 550 mm	25.5 kg	5 minutes
TNplus 10000	260 x 708 x 550 mm	84 kg	4 minutes
TNplus 10000S	260 x 708 x 550 mm	29.5 kg	4 minutes

(The letter “S” in the model designation indicates UPS without internal batteries and a built-in charger capable of supporting the connection of many external batteries for really large autonomies).
